Specifications chinacoal05
1 Compact and light
2 Stepless speed variation
3 Both clockwise and anticlockwise turning available
4 Safe, no danger of igni
Pneumatic winch/ air operated winch/ pneumatic lifting winch/ construction lifting winch/ explosion proof mining winch
1. pneumatic winch supply:
It has the advantages of compact structure,, convenient operation, safety and reliable operating, simple maintenance, smoothly running and stepless speed–changing etc. It is suitably used in oil field, well-drilling in oil field, mine-exploiting and other place with inflammable or easy exploding air.
To ensure the pneumatic winch works normally, make best use of it and prolong its working life, it is very important for users to install, operate and maintain it correctly and carefully. It is advisable that the consumers should read the manual book carefully before using it.
2. air operated winch features:
1 Compact and light
2 Stepless speed variation
3 Both clockwise and anticlockwise turning available
4 Safe, no danger of ignition and explosion in places with explosive gas
5 Strong moisture resistivity, so the safe operation is also available in rainy day, but unavailable for the electric hoist.
6 Big starting moment, load startup available
3. coal mine winch parameters:
Item | Specification |
Model | JQHS-50 | |
Max. lifting force | 50KN | |
Max. lifting speed | 12m/min | |
Rated power | 16KW | |
Air intake pressure | 0.8Mpa | |
Rated air consumption | 12.7m3/min | |
Wire capacity | 150m(Single brake) 120m(Double brake) | |
Diameter of wire | 20mm | |
Base connecting dimension | 912mmx500mm (High base) | |
| 912mmx392mm (low base) | |
Net weight | 550Kg (500Kg) | |
4. our other business scope: manual winch, small lifting winch, electric lifting winch, pneumatic winch, mining winch, mining pulling winches, and other customized winches on the base of your requirements.
4.pls feel free to inquiry, and the better quotation will be sent to you for your reference.
Product Tags:
|
|
Pneumatic - Air Winches Images
|
